Input Rating

Power

7500W

Current

0-120A

Voltage

0-500V

CC Model

Range

0-12A

0-120A

Resolution

1mA

10mA

Accuracy

0.05%+0.05%FS

0.05%+0.05%FS

CV Model

Range

0.1-19.999V

0.1-500V

Resolution

1mV

10mV

Accuracy

0.03%+0.02%FS

0.03%+0.05%FS

CR Model(Voltage and current input value ≥10% )

Range

0.03Ω-2K

0.03Ω-5K

Resolution

16 bit

16 bit

Accuracy

0.1%+0.1%FS

0.1%+0.15%FS

CW Model(Voltage and current input value ≥10%FS )

Range

0-7500W

0-7500W

Resolution

1mW

10mW

Accuracy

0.1%+0.1%FS

0.1%+0.15%FS

V Measurement

Voltage

0-19.999V

0-500V

Resolution

0.1mV

10mV

Accuracy

0.03%+0.03%FS

0.03%+0.05%FS

I Measurement

Current

0-12A

0-120A

Resolution

0.01mA

0.1mA

Accuracy

0.1%+0.1%FS

0.1%+0.15%FS

W Measurement(Voltage and current input value ≥10%FS )

Watt

100W

7500W

Resolution

1mW

10mW

Accuracy

0.1%+0.1%FS

0.1%+0.15%FS

Battery Measurement

  Battery Input: 0.5-500V; Max.   Measurement: Capacity=999AH;    Resolution=0.1mA;  Time   Range=1S-16HS

Dynamic Measurement

Transition  List:  0-25kHZ; 2.5A/μS;  T1&T2: 60μS-999S;  Accuracy: + 15% offset+10% FS

CC soft-startup Time

10mS; 20 mS; 50 mS; 100 mS; 200 mS     Accuracy: + 15% offset+10% FS

Short Circuit

Current(CC)

≒13.2A

≒132A

Voltage(CV)

0V

Resistance(CR)

≒30mΩ

Temperature

Operating

0～40℃

Non-operating

–10℃～70℃

Dimension

W*H*D(mm)

489.5*357*538.5

Weight

Kg

65
